Three Speed Wiring Instruction
1. Wiring Diagram:
N: COMMON
LC: LOW SPEED
LB: MIDDLE SPEED
LA: HIGH SPEED
2. Wiring with REB speed control:
Remark:To avoid influencing the fan service life,the optimal adjustable speed range is from 70%~100%.
3. Switch control:
N: COMMON
LC: LOW SPEED
LB: MIDDLE SPEED
LA: HIGH SPEED
